Door Switch Long Travel

Door Switch (SWP)-
Door Switch Long Travel

Place Of Origin	Guangdong, China (Mainland)
Brand Name	Unionwell
Model Number	SWP-SEL-O1U
Electrical Rating	0.25A 250VAC 0.5A 24VDC

The Features Of Door Switch Long Travel

Brand Name: Unionwell
Model Number: SWP-SEL-01U Door Switch
Rating: 0.25A 250VAC, 0.5A 24VDC
Application: Mainly used in the lighting and ventilation control of home appliances, such as refrigerators, freezers, etc.

The Parameters Of Door Switch Long Travel

Rating		0.25A 250VAC 0.5A 24VDC
Operating Frequency	Electrical	10~30 cycles/minute
	Mechanical	120 cycles/minute
Contact Resistance(initial value)		100mΩ Max
Insulation Resistance		100MΩ Min(At 500VDC)
Operating Temperature		-25°C~+60°C
Storage Temperature		-10°C~+45°C
Storage Humidity		10%~85%
Service Life	Electrical	100,000 cycles
	Mechanical	200,000 cycles

Our Advantage

Packing

Shipping

FAQ

Q1. Could you accept OEM or ODM?
A: Yes, we have a strong R&D team. We have rich experience in OEM&ODM.

Q2. Do you have micro switch patents?
A: Yes, we have more than 200 micro switch patents.

Q3. How many employees are in your factory?
A: There are over 600 employees at present in our factory.

Q4. How many engineers are in your R&D department?
A: Around 60 engineers in the R&D department, half of them own more than 20 years of micro switch experience.

Q5. What’s the capacity per month?
A: Over 8 million pieces per month for the micro switch series.
Over 20 million pieces per month for the keyboard switch series.
