The Features Of DPDT Limit Switches Long Life
Operating Frequency
Electrical: 60 cycles/minute
Mechanical: 180 cycles/minute
Service Life
Electrical: 1000,000 / cycles
Mechanical: 3000,000 / cycles
The Parameters Of DPDT Limit Switches Long Life
| Rating | DC14: 6A 12VDC; 2A 24VDC; 0.6A 55VDC |
|
| Operating Frequency | Electrical | 60 cycles/minute |
| Mechanical | 180 cycles/minute | |
| Contact Resistance(Initiative) | 100mΩ Max | |
| Insulation Resistance (at 500VDC) | 100MΩ Min | |
| Service Life | Electrical | 1000,000 cycles |
| Mechanical | 3000,000 cycles | |
| Storage Temperature |  -30°C~+85°C | |
| Storage Humidity | 95%RH Max | |
| Operating Temperature Range |  -30°C~+65°C | |
Our Advantage
Packing
Shipping
FAQ
Q1. Could you accept OEM or ODM?
A: Yes, we have a strong R&D team. We have rich experience in OEM&ODM.
Q2. Do you have micro switch patents?
A: Yes, we have more than 200 micro switch patents.
Q3. How many employees are in your factory?
A: There are over 600 employees at present in our factory.
Q4. How many engineers are in your R&D department?
A: Around 60 engineers in the R&D department, half of them own more than 20 years of micro switch experience.
Q5. What’s the capacity per month?
A: Over 8 million pieces per month for the micro switch series.
Over 20 million pieces per month for the keyboard switch series.
