The Features Of Push-Button Switch
- High contact reliability pushbutton switches for micro loads
- High stability in high temperature environment
- Have two function modes of self-locking and non-locking
- Feel smooth and good operating experience
- There are two welding process options of DIP and SMT
The Parameters Of Push-Button Switch
| Operating Frequency | 15~20/minute | |
| Insulation Resistance | ≥3MΩ（VDC 100V Insulation Resistance Meter） | |
| Contact Resistance(Initiative) | Terminals | ≤100mΩ |
| Dielectric Strength | Between Terminals of The Same Pole | AC100V,50/60HZ,1min. |
| Between Each Terminal and Non-live Metal Parts | AC1500V,50/60HZ,1min. | |
| Service Life | Electrical | 30，000/cycles(15~20/min) 1A 14.5VDC 10mA 5VDC |
| Mechanical | 300,000/cycles（60/min） | |
| Operating Temperature | -40～+85°C | |
| Operating Humidity | <95%RH（+5～+35°C） | |
Our Advantage
Packing
Shipping
FAQ
Q1. Could you accept OEM or ODM?
A: Yes, we have a strong R&D team. We have rich experience in OEM&ODM.
Q2. Do you have micro switch patents?
A: Yes, we have more than 200 micro switch patents.
Q3. How many employees are in your factory?
A: There are over 600 employees at present in our factory.
Q4. How many engineers are in your R&D department?
A: Around 60 engineers in the R&D department, half of them own more than 20 years of micro switch experience.
Q5. What’s the capacity per month?
A: Over 8 million pieces per month for the micro switch series.
Over 20 million pieces per month for the keyboard switch series.
